JASCO, a leading manufacturer of polarimeters since 1967, offers the P-2000 multi-option polarimeter for your laboratory needs.
The P-2000 is designed as a customizable polarimeter with various options for an array of applications and budgetary requirements. The system can also be field upgraded as application requirements change. Options for wavelength filters and source lamps provide a wide range of analytical wavelengths from UV-Vis to NIR.
Two graphical user interfaces are available including a newly redesigned intelligent remote module (iRM) with a color LCD touch screen and Spectra Manager™ II software, the latest version of JASCO's innovative cross-platform spectroscopy software. Both of these control and analysis interfaces allow full system control and advanced data processing. 21 CFR part 11 compliant versions for both interfaces can be ordered as an option.
The P-2000 offers a response speed as fast as six degrees per second to provide reproducible data for each measurement with a resolution of 0.0001°. A wide dynamic range of up to ±90° enables the system to measure chiral compounds over a broad range of concentrations. The sample chamber is equipped with an integrated temperature, the current temperature constantly updated on the instrument control screen.
In support of diverse applications, a full line of accessories including a variety of cylindrical cells: a demountable stainless steel cell, Peltier thermostatted cell holder, and monochromator options, all offered for functional expansions of the P-2000. Quick-connect fittings with flow control valves in the sample compartment provide simple and secure exchange of waterthermostatted cells for temperature control with water baths. A newly developed Peltier cell holder offers accurate temperature control with ±0.1° accuracy.
An automated validation program is available for GLP/cGMP laboratories or those regulated by the FDA. The program can be used for automated periodic validation of light source energy, zero repeatability, and rotational accuracy/repeatability. Inspected filters, sample cells with certified optical path length, and NIST-traceable rotation plates are also available.
With its single optical platform, the P-2000 can be customized to provide the optimum performance for every application. By selecting the most suitable combination of optical elements, the instrument can be used in the ultra-violet, visible and/or NIR regions.
|Principle||Automatic digital polarimeter with symmetric angular oscillation using the optical-null balance method|
|Light Source||Tungsten-Halogen lamp (WI), Sodium lamp (Na), Mercury lamp (Hg) (Up to two light sourcess can be installed.)|
|Wavelength||880, 633, 589, 578, 546, 436, 405, 365, 334, 325, 313, 302, 296, 280, 254 nm|
|Aperture||1.8, 3 and 8 mm diameters|
|Measurement Accuracy||±0.002° (up to 1°)|
|Repeatability||±0.2% (larger than 1°)
|Integration Time||1 - 100 sec|
|Detector||Photomultiplier tube (1P28-01) (R928 - option)|
|Readout Modes||Optical rotation, optical specific rotation, concentration, sugar scale Z, Brix purity, optical purity|
|Temperature Measurement Range||0~40°C (minimum display temperature: 0.1°C)|
|Dimensions||653 (W) x 249 (D) x 364 (H) mm|
|Weight||Approx. 30 kg|
|Power Requirement||AC100~240V ±10%, 50 or 60 Hz, 80 - 300 W|
A validation program is included as standard for GLP/cGMP laboratories or those regulated by the FDA. The program can be used for periodic validation of light source energy, zero repeatability, and rotational accuracy/repeatability. Inspected filters, sample cells with a certified optical path length, and NIST-traceable quartz rotation plates are also available as options.
The P-2000 Digital Polarimeter provides a wide range of choices for the control system, light source, cell, cell holder and wavelengths ranging from the UV-Vis to the NIR. A system optimized for any requirement can be configured for the laboratory, including only those items required for the desired application(s).
Rather than plural models, with no way to update functions, JASCO offers a single model to be configured in order to optimally meet your application requirements, yet easy to upgrade in the field, with a wide choice of available accessories.
For more information, click one of the applications of the P-2000 Series Digital Polarimeter below:
